Smart WiFi Circuit Breaker Time Timer Relay Switch Voice Remote Control

There are different options in this auction, you can switch options via button above “Buy Now”. Please make sure you have chosen the right option before placing an order.

18mm Din Rail WIFI Smart Switch Remote control by Tuya APP for Smart home

Standard：GB109631/ IEC60898

Feature：

1.Remote control at anytime from anywhere

2.Timer ON/OFF

3.Scene setting, home scene（Turn on the light, turn on the water heater, turn on the TV, turn on the air conditioner,）,

going out scene(Turn off the lights, turn off the water heater, turn off the TV, turn off the air conditioner, etc.）

4.Sharing devices with family and friends

5.18 mm Din Rail install

Specification：

Rated Voltage ：AC100-240V (Single phase) ， AC100-400V (Three phase)

Rated Current：32A/50A/63A/80A Frequency：50/60Hz

Poles：1P+N/3P+N

Control： Remote control Connection 2.4G WIFI

Note: Only Single phase 63/80A has energy meter function

Checklist before using the device:
1.Your smart  Phone should be connected 2.4G WIFI with internet
2.Down the tuya App from App Store or Google Play store， create an account and log in.

3.During pairing process, make sure that your IOS or Android device and the Tuya device is within the range of the router.

4.The device only supports 2.4G network Please don't connect to a 5G network or hybrid network

5.Enter correct WIFI passwords ,Make sure that your WIFI SSID and Passwords don't contain special characters

Brand Name: EARUELETRIC
Origin: CN(Origin)
Certification: CE
Type: Mini
Is Smart Device: YES
Model Number: EAWCB-TUYA-1/2/4P
Feature: Remote control at anytime from anywhere
Control Way: Smart Phone/ TUYA APP
Connect: WIFI
Feedback: Real Time Status Feedback
Share: Share with All Family Mebmer
Set: Scene Set/Go out home / Arrive home
APP: Tuya
Function1: Smart Switch
Function2: Power Meter (Only for 1P+N 63/80A)
Working Voltage: Single Phase 100-240V/ Three Phases 100-400V
Rated Current: 32A/50A/63A/80A
Frequency: 50/60Hz
